Frota
Frota Starnav
Conheça mais sobre a nossa frota de embarcações
Starnav Perseus
Starnav Centaurus
Starnav Ursus
Starnav Regulus
Starnav Aquarius
Starnav Taurus
Starnav Andromeda
Starnav Draco
Starnav Phoenix
Starnav Aquila
Starnav Cepheus
Starnav Cygnus
Starnav Volans
Starnav Scorpius
Starnav Hydra
Starnav Libra
Starnav Circinus
Starnav Delphinus
Starnav Perseus
Especificações Técnicas
GPA 688 SC – PSV 4.500 – Fluid Carrier
Built | Yard: 2013 - Detroit Brasil Ltda.
Main Class: A1, OffShore Support Vessel, AMS, DPS-2, ACCU, E Circle
LOA: 90,0m
Breadth Moulded: 19,0m
Draft (máx – IBC:T2): 5,84m
Draft (máx – non IBC:T2): 6,34m
Deadweight: 4700mt (d=5,84) / 5400mt (d=6,34)
Gross Tonnage: 4427
Deck Dimensions: 843,72m² (53,4m x 15,8m)
Deck Load | Strength: 3000mt | 5mt/m²
FuelOil (96%): 297,2m³
PotWater (100%): 172,20m³
DrillWater / WB (100%): 2060,60m³
Synthetic Oil Base Mud (96%): 1159,2m³
Hydrocarbon Oil Base Mud (96%): 289,8m³
Water Base Mud (96%): 589,59m³
Brine: 1493,60m³
Dry Bulk: 330 m³ (5 tanks)
Provision Cargo Crane: 30kN – max. 9m radius
Tugger Winches: 2 x 60kN @ 24 m/min
Main Engines (Gen-Set): 4 x 2080KW = 8320 kW (11153 BHP)
Bow Thrusters: 2 x 750kW = 1500 kW (2011BHP)
Azimuth Thrusters: 2 x 2500kW = 5000 kW (6702 BHP)
Consumption at Economy Speed: 17m³ / 24hrs @ 10Knots
Consumption at Service Speed: 24m³ / 24hrs @ 13Knots
Total Capacity: 30 Persons
Starnav Centaurus
Especificações Técnicas
GPA 688 SC – PSV 4.500 – Fluid Carrier
Built | Yard: 2013 - Detroit Brasil Ltda.
Main Class: A1, OffShore Support Vessel, AMS, DPS-2, ACCU, E Circle
LOA: 90,0m Breadth Moulded: 19,0m
Draft (máx – IBC:T2): 5,84m
Draft (máx – non IBC:T2): 6,34m
Deadweight: 4700mt (d=5,84) / 5400mt (d=6,34)
Gross Tonnage: 4427
Deck Dimensions: 843,72m² (53,4m x 15,8m)
Deck Load | Strength: 3000mt | 5mt/m²
FuelOil (96%): 297,2m³
PotWater (100%): 172,20m³
DrillWater / WB (100%): 2060,60m³
Synthetic Oil Base Mud (96%): 1159,2m³
Hydrocarbon Oil Base Mud (96%): 289,8m³ Water Base Mud (96%): 589,59m³
Brine: 1493,60m³
Dry Bulk: 330 m³ (5 tanks)
Provision Cargo Crane: 30kN – max. 9m radius
Tugger Winches: 2 x 60kN @ 24 m/min
Main Engines (Gen-Set): 4 x 2080KW = 8320 kW (11153 BHP)
Bow Thrusters: 2 x 750kW = 1500 kW (2011BHP)
Azimuth Thrusters: 2 x 2500kW = 5000 kW (6702 BHP)
Consumption at Economy Speed: 17m³ / 24hrs @ 10Knots
Consumption at Service Speed: 24m³ / 24hrs @ 13Knots
Total Capacity: 30 Persons
Starnav Ursus
Especificações Técnicas
GPA 688 SC – PSV 4.500 – Fluid Carrier
Built | Yard: 2013 - Detroit Brasil Ltda.
Main Class: A1, OffShore Support Vessel, AMS, DPS-2, ACCU, E Circle
LOA: 90,0m
Breadth Moulded: 19,0m
Draft (máx – IBC:T2): 5,84m
Draft (máx – non IBC:T2): 6,34m
Deadweight: 4700mt (d=5,84) / 5400mt (d=6,34)
Gross Tonnage: 4427
Deck Dimensions: 843,72m² (53,4m x 15,8m)
Deck Load | Strength: 3000mt | 5mt/m² FuelOil (96%): 297,2m³
PotWater (100%): 172,20m³
DrillWater / WB (100%): 2060,60m³
Synthetic Oil Base Mud (96%): 1159,2m³
Hydrocarbon Oil Base Mud (96%): 289,8m³
Water Base Mud (96%): 589,59m³
Brine: 1493,60m³
Dry Bulk: 330 m³ (5 tanks)
Provision Cargo Crane: 30kN – max. 9m radius
Tugger Winches: 2 x 60kN @ 24 m/min
Main Engines (Gen-Set): 4 x 2080KW = 8320 kW (11153 BHP)
Bow Thrusters: 2 x 750kW = 1500 kW (2011BHP)
Azimuth Thrusters: 2 x 2500kW = 5000 kW (6702 BHP)
Consumption at Economy Speed: 17m³ / 24hrs @ 10Knots
Consumption at Service Speed: 24m³ / 24hrs @ 13Knots
Total Capacity: 30 Persons
Starnav Regulus
Especificações Técnicas
GPA 688 SC – PSV 4.500 – Fluid Carrier
Built | Yard: 2014 - Detroit Brasil Ltda.
Main Class: A1, OffShore Support Vessel, AMS, DPS-2, ACCU, E Circle
LOA: 90,0m
Breadth Moulded: 19,0m
Draft (máx – IBC:T2): 5,84m
Draft (máx – non IBC:T2): 6,34m
Deadweight: 4700mt (d=5,84) / 5400mt (d=6,34)
Gross Tonnage: 4427
Deck Dimensions: 843,72m² (53,4m x 15,8m)
Deck Load | Strength: 3000mt | 5mt/m²
FuelOil (96%): 297,2m³
PotWater (100%): 172,20m³
DrillWater / WB (100%): 2060,60m³
Synthetic Oil Base Mud (96%): 1159,2m³
Hydrocarbon Oil Base Mud (96%): 289,8m³
Water Base Mud (96%): 589,59m³
Brine: 1493,60m³
Dry Bulk: 330 m³ (5 tanks)
Provision Cargo Crane: 30kN – max. 9m radius
Tugger Winches: 2 x 60kN @ 24 m/min
Main Engines (Gen-Set): 4 x 2080KW = 8320 kW (11153 BHP)
Bow Thrusters: 2 x 750kW = 1500 kW (2011BHP)
Azimuth Thrusters: 2 x 2500kW = 5000 kW (6702 BHP)
Consumption at Economy Speed: 17m³ / 24hrs @ 10Knots
Consumption at Service Speed: 24m³ / 24hrs @ 13Knots
Total Capacity: 30 Persons
Starnav Aquarius
Especificações Técnicas
GPA 688 SC – PSV 4.500 – Fluid Carrier
Built | Yard: 2013 - Detroit Brasil Ltda.
Main Class: A1, OffShore Support Vessel, AMS, DPS-2, ACCU, E Circle
LOA: 90,0m
Breadth Moulded: 19,0m
Draft (máx – IBC:T2): 5,84m
Draft (máx – non IBC:T2): 6,34m
Deadweight: 4700mt (d=5,84) / 5400mt (d=6,34)
Gross Tonnage: 4427
Deck Dimensions: 843,72m² (53,4m x 15,8m)
Deck Load | Strength: 3000mt | 5mt/m²
FuelOil (96%): 297,2m³
PotWater (100%): 172,20m³
DrillWater / WB (100%): 2060,60m³
Synthetic Oil Base Mud (96%): 1159,2m³
Hydrocarbon Oil Base Mud (96%): 289,8m³
Water Base Mud (96%): 589,59m³
Brine: 1493,60m³
Dry Bulk: 330m³ (5 tanks)
Provision Cargo Crane: 30kN – max. 9m radius
Tugger Winches: 2 x 60kN @ 24 m/min
Main Engines (Gen-Set): 4 x 2080KW = 8320 kW (11153 BHP)
Bow Thrusters: 2 x 750kW = 1500 kW (2011BHP)
Azimuth Thrusters: 2 x 2500kW = 5000 kW (6702 BHP)
Consumption at Economy Speed: 17m³ / 24hrs @ 10Knots
Consumption at Service Speed: 24m³ / 24hrs @ 13Knots
Total Capacity: 30 Persons
Starnav Taurus
Especificações Técnicas
GPA 688 SC – PSV 5.000 –General Cargo
Built | Yard: 2014 - Detroit Brasil Ltda.
MainClass: A1, Offshore Support Vessel, AMS, DPS-2, ACCU, E Circle, UWILD
LOA: 90,0m
Breadth Moulded: 19,0m
Draft máx.: 6,34m
Deadweight: 5400mt (d=6,34m)
Gross Tonnage: 4427
Deck Dimensions: 921m² (58,27m x 15,8m)
Deck Load: 3000mt
Deck Strength: 5mt/m²
Ship Fuel Oil (96%): 349m³
Ship Potable Water (100%): 298m³
Segregation 1 (potable water 100%): 2640m³
Segregation 2 (marine diesel oil 96%): 592m³
Segregation 3 (marine diesel oil 96%): 508m³
DrillWater / WB (100%): 2060m³
Deck Cranes: Two (2) movable cargo rail cranes. Each: 10t@10m, 6t@16m
Main Engines (Gen Sets): 4 x 2080KW = 8320 kW (11153 BHP)
Bow Thrusters: 2 x 900kW = 1800 kW (2420 BHP)
Azimuth Thrusters (Main Propulsion): 2 x 2500kW = 5000 kW (6702 BHP)
Consumption at Economy Speed: 17m³ / 24hrs @ 10Knots
Consumption at Service Speed: 24m³ / 24hrs @ 13Knots
Total Capacity: 30 Persons
Starnav Andromeda
Especificações Técnicas
GPA 688 SCT – PSV 5.000 – General Cargo
Built | Yard: 2014 - Detroit Brasil Ltda.
MainClass: A1, Offshore Support Vessel, AMS, DPS-2, ACCU, E Circle, UWILD
LOA: 90,0m
Breadth Moulded: 19,0m
Draft máx.: 6,34m
Deadweight: 5400mt (d=6,34m)
Gross Tonnage: 4427
Deck Dimensions: 921m² (58,27m x 15,8m)
Deck Load: 3000mt
Deck Strength: 5mt/m²
Ship Fuel Oil (96%): 349m³
Ship Potable Water (100%): 298m³
Segregation 1 (potable water 100%): 2640m³
Segregation 2 (marine diesel oil 96%): 592m³
Segregation 3 (marine diesel oil 96%): 508m³
DrillWater / WB (100%): 2060m³
Deck Cranes: Two (2) movable cargo rail cranes. Each: 10t@10m, 6t@16m
Main Engines (Gen Sets): 4 x 2080KW = 8320 kW (11153 BHP)
Bow Thrusters: 2 x 900kW = 1800 kW (2420 BHP)
Azimuth Thrusters (Main Propulsion): 2 x 2500kW = 5000 kW (6702 BHP)
Consumption at Economy Speed: 17m³ / 24hrs @ 10Knots
Consumption at Service Speed: 24m³ / 24hrs @ 13Knots
Total Capacity: 30 Persons
Starnav Draco
Especificações Técnicas
GPA 688 SCT – PSV 5.000 – General Cargo
Built | Yard: 2014 - Detroit Brasil Ltda.
MainClass: A1, Offshore Support Vessel, AMS, DPS-2, ACCU, E Circle, UWILD
LOA: 90,0m
Breadth Moulded: 19,0m
Draft máx.: 6,34m
Deadweight: 5400mt (d=6,34m)
Gross Tonnage: 4427
Deck Dimensions: 921m² (58,27m x 15,8m)
Deck Load: 3000mt
Deck Strength: 5mt/m²
Ship Fuel Oil (96%): 349m³
Ship Potable Water (100%): 298m³
Segregation 1 (potable water 100%): 2640m³
Segregation 2 (marine diesel oil 96%): 592m³
Segregation 3 (marine diesel oil 96%): 508m³
DrillWater / WB (100%): 2060m³
Deck Cranes: Two (2) movable cargo rail cranes. Each: 10t@10m, 6t@16m
Main Engines (Gen Sets): 4 x 2080KW = 8320 kW (11153 BHP)
Bow Thrusters: 2 x 900kW = 1800 kW (2420 BHP)
Azimuth Thrusters (Main Propulsion): 2 x 2500kW = 5000 kW (6702 BHP)
Consumption at Economy Speed: 17m³ / 24hrs @ 10Knots
Consumption at Service Speed: 24m³ / 24hrs @ 13Knots
Total Capacity: 30 Persons
Starnav Phoenix
Especificações Técnicas
GPA 688 SCT – PSV 5.000 – General Cargo
Built | Yard: 2015 - Detroit Brasil Ltda.
MainClass: A1, Offshore Support Vessel, AMS, DPS-2, ACCU, E Circle, UWILD
LOA: 90,0m
Breadth Moulded: 19,0m
Draft máx.: 6,34m
Deadweight: 5400mt (d=6,34m)
Gross Tonnage: 4427
Deck Dimensions: 921m² (58,27m x 15,8m)
Deck Load: 3000mt
Deck Strength: 5mt/m²
Ship Fuel Oil (96%): 349m³
Ship Potable Water (100%): 298m³
Segregation 1 (potable water 100%): 2640m³
Segregation 2 (marine diesel oil 96%): 592m³
Segregation 3 (marine diesel oil 96%): 508m³
DrillWater / WB (100%): 2060m³
Deck Cranes: Two (2) movable cargo rail cranes. Each: 10t@10m, 6t@16m
Main Engines (Gen Sets): 4 x 2080KW = 8320 kW (11153 BHP)
Bow Thrusters: 2 x 900kW = 1800 kW (2420 BHP)
Azimuth Thrusters (Main Propulsion): 2 x 2500kW = 5000 kW (6702 BHP)
Consumption at Economy Speed: 17m³ / 24hrs @ 10Knots
Consumption at Service Speed: 24m³ / 24hrs @ 13Knots
Total Capacity: 30 Persons
Starnav Aquila
Especificações Técnicas
GPA 688 SCT – PSV 5.000 – General Cargo
Built | Yard: 2015 - Detroit Brasil Ltda.
MainClass: A1, Offshore Support Vessel, AMS, DPS-2, ACCU, E Circle, UWILD
LOA: 90,0m
Breadth Moulded: 19,0m
Draft máx.: 6,34m
Deadweight: 5400mt (d=6,34m)
Gross Tonnage: 4427
Deck Dimensions: 921m² (58,27m x 15,8m)
Deck Load: 3000mt
Deck Strength: 5mt/m²
Ship Fuel Oil (96%): 349m³
Ship Potable Water (100%): 298m³
Segregation 1 (potable water 100%): 2640m³
Segregation 2 (marine diesel oil 96%): 592m³
Segregation 3 (marine diesel oil 96%): 508m³
DrillWater / WB (100%): 2060m³
Deck Cranes: Two (2) movable cargo rail cranes. Each: 10t@10m, 6t@16m
Main Engines (Gen Sets): 4 x 2080KW = 8320 kW (11153 BHP)
Bow Thrusters: 2 x 900kW = 1800 kW (2420 BHP)
Azimuth Thrusters (Main Propulsion): 2 x 2500kW = 5000 kW (6702 BHP)
Consumption at Economy Speed: 17m³ / 24hrs @ 10Knots
Consumption at Service Speed: 24m³ / 24hrs @ 13Knots
Total Capacity: 30 Persons
Starnav Cepheus
Especificações Técnicas
GPA 688 SCT – PSV 5.000 – General Cargo
Built | Yard: 2016 - Detroit Brasil Ltda.
MainClass: A1, Offshore Support Vessel, AMS, DPS-2, ACCU, E Circle, UWILD
LOA: 90,0m
Breadth Moulded: 19,0m
Draft máx.: 6,34m
Deadweight: 5400mt (d=6,34m)
Gross Tonnage: 4427
Deck Dimensions: 921m² (58,27m x 15,8m)
Deck Load: 3000mt
Deck Strength: 5mt/m²
Ship Fuel Oil (96%): 349m³
Ship Potable Water (100%): 298m³
Segregation 1 (potable water 100%): 2640m³
Segregation 2 (marine diesel oil 96%): 592m³
Segregation 3 (marine diesel oil 96%): 508m³
DrillWater / WB (100%): 2060m³
Deck Cranes: Two (2) movable cargo rail cranes. Each: 10t@10m, 6t@16m
Main Engines (Gen Sets): 4 x 2080KW = 8320 kW (11153 BHP)
Bow Thrusters: 2 x 900kW = 1800 kW (2420 BHP)
Azimuth Thrusters (Main Propulsion): 2 x 2500kW = 5000 kW (6702 BHP)
Consumption at Economy Speed: 17m³ / 24hrs @ 10Knots
Consumption at Service Speed: 24m³ / 24hrs @ 13Knots
Total Capacity: 30 Persons
Starnav Cygnus
Especificações Técnicas
GPA 688 SCT – PSV 5.000 – General Cargo
Built | Yard: 2016 - Detroit Brasil Ltda.
MainClass: A1, Offshore Support Vessel, AMS, DPS-2, ACCU, E Circle, UWILD
LOA: 90,0m
Breadth Moulded: 19,0m
Draft máx.: 6,34m
Deadweight: 5400mt (d=6,34m)
Gross Tonnage: 4427
Deck Dimensions: 921m² (58,27m x 15,8m)
Deck Load: 3000mt
Deck Strength: 5mt/m²
Ship Fuel Oil (96%): 349m³
Ship Potable Water (100%): 298m³
Segregation 1 (potable water 100%): 2640m³
Segregation 2 (marine diesel oil 96%): 592m³
Segregation 3 (marine diesel oil 96%): 508m³
DrillWater / WB (100%): 2060m³
Deck Cranes: Two (2) movable cargo rail cranes. Each: 10t@10m, 6t@16m
Main Engines (Gen Sets): 4 x 2080KW = 8320 kW (11153 BHP)
Bow Thrusters: 2 x 900kW = 1800 kW (2420 BHP)
Azimuth Thrusters (Main Propulsion): 2 x 2500kW = 5000 kW (6702 BHP)
Consumption at Economy Speed: 17m³ / 24hrs @ 10Knots
Consumption at Service Speed: 24m³ / 24hrs @ 13Knots
Total Capacity: 30 Persons
Starnav Volans
Especificações Técnicas
GPA 688 SCT – PSV 5.000 – General Cargo
Built | Yard: 2016 - Detroit Brasil Ltda.
MainClass: A1, Offshore Support Vessel, AMS, DPS-2, ACCU, E Circle, UWILD
LOA: 90,0m
Breadth Moulded: 19,0m
Draft máx.: 6,34m
Deadweight: 5400mt (d=6,34m)
Gross Tonnage: 4427
Deck Dimensions: 921m² (58,27m x 15,8m)
Deck Load: 3000mt
Deck Strength: 5mt/m²
Ship Fuel Oil (96%): 349m³
Ship Potable Water (100%): 298m³
Segregation 1 (potable water 100%): 2640m³
Segregation 2 (marine diesel oil 96%): 592m³
Segregation 3 (marine diesel oil 96%): 508m³
DrillWater / WB (100%): 2060m³ Deck Cranes: Two (2) movable cargo rail cranes. Each: 10t@10m, 6t@16m
Main Engines (Gen Sets): 4 x 2080KW = 8320 kW (11153 BHP)
Bow Thrusters: 2 x 900kW = 1800 kW (2420 BHP)
Azimuth Thrusters (Main Propulsion): 2 x 2500kW = 5000 kW (6702 BHP)
Consumption at Economy Speed: 17m³ / 24hrs @ 10Knots
Consumption at Service Speed: 24m³ / 24hrs @ 13Knots
Total Capacity: 30 Persons
Starnav Scorpius
Especificações Técnicas
GPA 688 SCT – PSV 5.000 – General Cargo
Built | Yard: 2016 - Detroit Brasil Ltda.
MainClass: A1, Offshore Support Vessel, AMS, DPS-2, ACCU, E Circle, UWILD
LOA: 90,0m
Breadth Moulded: 19,0m
Draft máx.: 6,34m
Deadweight: 5400mt (d=6,34m)
Gross Tonnage: 4427
Deck Dimensions: 921m² (58,27m x 15,8m)
Deck Load: 3000mt
Deck Strength: 5mt/m²
Ship Fuel Oil (96%): 349m³
Ship Potable Water (100%): 298m³
Segregation 1 (potable water 100%): 2640m³
Segregation 2 (marine diesel oil 96%): 592m³
Segregation 3 (marine diesel oil 96%): 508m³
DrillWater / WB (100%): 2060m³
Deck Cranes: Two (2) movable cargo rail cranes. Each: 10t@10m, 6t@16m
Main Engines (Gen Sets): 4 x 2080KW = 8320 kW (11153 BHP)
Bow Thrusters: 2 x 900kW = 1800 kW (2420 BHP)
Azimuth Thrusters (Main Propulsion): 2 x 2500kW = 5000 kW (6702 BHP)
Consumption at Economy Speed: 17m³ / 24hrs @ 10Knots
Consumption at Service Speed: 24m³ / 24hrs @ 13Knots
Total Capacity: 30 Persons
Starnav Hydra
Especificações Técnicas
GPA 688 SCT – PSV 5.000 – General Cargo
Built | Yard: 2017 - Detroit Brasil Ltda.
MainClass: A1, Offshore Support Vessel, AMS, DPS-2, ACCU, E Circle, UWILD
LOA: 90,0m
Breadth Moulded: 19,0m
Draft máx.: 6,34m
Deadweight: 5400mt (d=6,34m)
Gross Tonnage: 4427
Deck Dimensions: 921m² (58,27m x 15,8m)
Deck Load: 3000mt
Deck Strength: 5mt/m²
Ship Fuel Oil (96%): 349m³
Ship Potable Water (100%): 298m³
Segregation 1 (potable water 100%): 2640m³
Segregation 2 (marine diesel oil 96%): 592m³
Segregation 3 (marine diesel oil 96%): 508m³
DrillWater / WB (100%): 2060m³
Deck Cranes: Two (2) movable cargo rail cranes. Each: 10t@10m, 6t@16m
Main Engines (Gen Sets): 4 x 2080KW = 8320 kW (11153 BHP)
Bow Thrusters: 2 x 900kW = 1800 kW (2420 BHP)
Azimuth Thrusters (Main Propulsion): 2 x 2500kW = 5000 kW (6702 BHP)
Consumption at Economy Speed: 17m³ / 24hrs @ 10Knots
Consumption at Service Speed: 24m³ / 24hrs @ 13Knots
Total Capacity: 30 Persons
Starnav Libra
Especificações Técnicas
GPA 688 SCT – PSV 5.000 – General Cargo
Built | Yard: 2017 - Detroit Brasil Ltda.
MainClass: A1, Offshore Support Vessel, AMS, DPS-2, ACCU, E Circle, UWILD
LOA: 90,0m
Breadth Moulded: 19,0m
Draft máx.: 6,34m
Deadweight: 5400mt (d=6,34 m)
Gross Tonnage: 4427
Deck Dimensions: 921m² (58,27m x 15,8m)
Deck Load: 3000mt
Deck Strength: 5mt/m²
Ship Fuel Oil (96%): 349m³
Ship Potable Water (100%): 298m³
Segregation 1 (potable water 100%): 2640m³
Segregation 2 (marine diesel oil 96%): 592m³
Segregation 3 (marine diesel oil 96%): 508m³
DrillWater / WB (100%): 2060m³
Deck Cranes: Two (2) movable cargo rail cranes. Each: 10t@10m, 6t@16m
Main Engines (Gen Sets): 4 x 2080KW = 8320 kW (11153 BHP)
Bow Thrusters: 2 x 900kW = 1800 kW (2420 BHP)
Azimuth Thrusters (Main Propulsion): 2 x 2500kW = 5000 kW (6702 BHP)
Consumption at Economy Speed: 17m³ / 24hrs @ 10Knots
Consumption at Service Speed: 24m³ / 24hrs @ 13Knots
Total Capacity: 30 Persons
Starnav Circinus
Especificações Técnicas
GPA 688 SCT – PSV 5.000 – General Cargo
Built | Yard: 2017 - Detroit Brasil Ltda.
MainClass: A1, Offshore Support Vessel, AMS, DPS-2, ACCU, E Circle, UWILD
LOA: 90,0m
Breadth Moulded: 19,0m
Draft máx.: 6,34m
Deadweight: 5400mt (d=6,34m)
Gross Tonnage: 4427
Deck Dimensions: 921m² (58,27m x 15,8m)
Deck Load: 3000mt
Deck Strength: 5mt/m²
Ship Fuel Oil (96%): 349m³
Ship Potable Water (100%): 298m³
Segregation 1 (potable water 100%): 2640m³
Segregation 2 (marine diesel oil 96%): 592m³
Segregation 3 (marine diesel oil 96%): 508m³
DrillWater / WB (100%): 2060m³
Deck Cranes: Two (2) movable cargo rail cranes. Each: 10t@10m, 6t@16m
Main Engines (Gen Sets): 4 x 2080KW = 8320 kW (11153 BHP)
Bow Thrusters: 2 x 900kW = 1800 kW (2420 BHP)
Azimuth Thrusters (Main Propulsion): 2 x 2500kW = 5000 kW (6702 BHP)
Consumption at Economy Speed: 17m³ / 24hrs @ 10Knots
Consumption at Service Speed: 24m³ / 24hrs @ 13Knots
Total Capacity: 30 Persons
Starnav Delphinus
Especificações Técnicas
GPA 688 SCT – PSV 5.000 – General Cargo
Built | Yard: 2017 - Detroit Brasil Ltda.
MainClass: A1, Offshore Support Vessel, AMS, DPS-2, ACCU, E Circle, UWILD
LOA: 90,0m
Breadth Moulded: 19,0m
Draft máx.: 6,34m
Deadweight: 5400mt (d=6,34m)
Gross Tonnage: 4427
Deck Dimensions: 921m² (58,27m x 15,8m)
Deck Load: 3000mt
Deck Strength: 5mt/m²
Ship Fuel Oil (96%): 349 m³
Ship Potable Water (100%): 298 m³
Segregation 1 (potable water 100%): 2640 m³
Segregation 2 (marine diesel oil 96%): 592m³
Segregation 3 (marine diesel oil 96%): 508m³
DrillWater / WB (100%): 2060m³
Deck Cranes: Two (2) movable cargo rail cranes. Each: 10t@10m, 6t@16m
Main Engines (Gen Sets): 4 x 2080KW = 8320 kW (11153 BHP)
Bow Thrusters: 2 x 900kW = 1800 kW (2420 BHP)
Azimuth Thrusters (Main Propulsion): 2 x 2500kW = 5000 kW (6702 BHP)
Consumption at Economy Speed: 17m³ / 24hrs @ 10Knots
Consumption at Service Speed: 24m³ / 24hrs @ 13Knots
Total Capacity: 30 Persons
